Product introduction:







Accurate positioning of projection, controllable beam radiation angle.



Stable array performance, convenient and flexible design system audio signal after phase correction processing, ensure flat frequency characteristics and phase response, bring extraordinary impulse response and accurate sound image restoration. Extraordinary fidelity and peak power ensure a flat and shocking frequency response. A constant Q-value treble unit can perform a very uniform response throughout the sound coverage area.







Technical parameters:







Frequency response: (+3dB) 52HZ-18KHZ



Rated power: 1200W (2400w peak), 100 hours



Maximum SPL (1m) 132dB (peak 138dB)



Weight: 48 kg



Size: 560 x 980 x 305mm



Low Frequency Driver: 3 x 310 mm (12 in) coil diameter, 65 mm (2.5 in)



High Frequency Driver: 3 x 25mm (1in)



3 x 8 ohm discrete driving mode



Nominal impedance: 3 ohms



Parallel driving mode
